Pocket Nc Mill
Equipment size:600x400x510mm
bed dimension:φ100mm
Maximum payloadof the work table:5kg
Description
Technical Parameters
Products Description
pocket nc mill
The Pocket NC Mill is a 5-axis desktop CNC machine designed for personal invention, digital education and economical production. It stands out in the market for its powerful processing capabilities and compact design, enabling rapid and low-cost design and manufacturing on the desktop. The device is controlled by the Windows system, supports precision milling through CAD or CAM software, and is compatible with G-code control. The spindle speed can reach 0-24000rpm, meeting the various needs of professional designers. It can mill a variety of materials such as plastic, aluminum alloy, wood, copper, gold, silver, wax, etc., and is equipped with replaceable tool heads, which are easy to operate and do not require additional tools.
Five-axis machining capability
Pocket NC Mill has five-axis linkage function, capable of machining complex geometries, suitable for high-precision, multi-angle cutting tasks.
Desktop-level compact design
The device is compact and occupies little space, suitable for use in a desktop environment, providing efficient manufacturing solutions for individual users and small studios.
Multi-material compatibility
Supports milling of a variety of materials, including plastics, aluminum alloys, wood, copper, precious metals and wax, to meet a wide range of processing needs.
User-friendly operating system
Controlled by Windows system, compatible with CAD/CAM software and G-code, supports quick start and flexible programming, suitable for users of different skill levels.
| Packing Size | W800xD600xH800mm | Packing weight | 100-120kg |
| Equipment size | W600xD400x H510mm | weightof equipment | Net weight of45kg,with sheet metal of 75kg |
| bed dimension | φ100mm | Maximum payload of the work table |
5kg |
| XYZ effective travel |
X160xY200xZ130mm | AC effective travel | A:-30-120°,C 360° |
| Three axis processing range | X160xY200xZ125mm | Five axisprocessing range |
Cylinder:φ 150 H105mm,φ 100 H120mm,cube W125D 125 H110mm |
| Three-axis processing accuracy | Linear axis parallelism & vertical degree of 0.03mm, Travel range is 0.02mm |
Five axis processing accuracy |
Linear axis parallelism &vertical degree of 0.05mm, Fve-axis spatial accuracy of<0.05mm |
| XYZ ball wire rod | X&Z:1204C7,Y:1604 C7,up gradable C5 | AC axle |
1:80 20 Harmonic reducer return<1' |
| The XYZ linear guide rail | X&Z Hiwin MGN12 Y:Hiwin MGN15 | body frame | 6061T6 aviation aluminum+stressed component adjustment of 45 steel |
| Processing speed | 4000mm/min vary by material | ||
| principal axis | φ65mm 800W Water-cooled electric spindle at 24,000r /min |
protect | Organ is dust-proof +oil seal is waterproof and dustproof |
| Tool diameter& length | ER11.0-8mm,≤75mm | Part fixtures | Steel fixture with reserved hole position Can add er50 clip holder,63,80 card |
| work materia | Metal:auminum alloy.copper alloy,gold alloy,silver Non-metat plastic,wood,wax,jade,glass alloy.*steel,*titanium alloy etc |
||
Function
High-performance spindle: 800w high power, 24000rpm high speed, efficient water cooling, shaft radial runout 3-5 μm.
High-precision accessories: rotary axis harmonic motor, linear axis DC servo motor + ball line rod + silver linear guide
Sheet metal chassis: noise reduction, waterproof treatment of key components, and cutting fluid circulation system
Simple operation: automatic tool setting, electronic handwheel
Low-cost manufacturing
Professional technical services: CAM programming and simulation guidance, computer training, fixture customization, accessories customization upgrade, etc.
* Recommended CAM software: PowerM sick, Fusion360, UG
* Post-processing program: Power Mill, UG, Fusion360 and HSM
* Motion simulation software: Power Mill, Vericut
Applications of 5-axis CNc machine
Complex Parts Machining:
The five-axis linkage capability of Pocket NC Mill makes it suitable for machining complex geometries, especially small parts that require precision machining in fields such as aerospace and automotive manufacturing.
Mold Manufacturing
Mold Manufacturing: Suitable for manufacturing high-precision molds, capable of handling complex contours and curved surfaces, widely used in fields such as injection molding and die casting, ensuring the quality and consistency of the final product.
Prototyping
Prototyping: Capable of quickly making prototypes of various materials, suitable for the product development stage, helping designers to verify and improve design solutions.
Education and Training
Education and Training: Due to its compact design and easy operation, Pocket NC Mill is widely used in educational and training institutions to help students and professionals learn CNC machining technology.
Supporting milling of precious metals and wax, Pocket NC Mill can be used for precision machining in jewelry making, such as making custom jewelry and ornaments with complex details.
The device can process materials such as wood and plastic, suitable for making crafts, architectural models and ornaments, meeting the needs of high-precision handicrafts.
Video: https://youtu.be/TNFE7E83VMU xslightings@xslightings.com wechat id:13305858081
FAQ
Who is this device suitable for?
The Pocket NC Mill is suitable for individual inventors, digital education institutions, small studios, and small manufacturers who need high-precision processing.
Why choose a small 5-axis CNc machine for manufacturing miniature components?
Small 5-axis CNc machines offer precise control over machining operations, making them ideal for producing miniature componentswith intricate details and tight tolerances
How to achieve five-axis linkage machining through 5-axis CNc machines?
Answer: Users can generate five-axis linkage G code through CAD/CAM software and directly import it into 5-axis CNc machines for high-precision machining of complex surfaces.
Is the spindle speed adjustable?
Yes, the Pocket NC Mill has a spindle speed range of 0-24000rpm, which can be adjusted according to the material and processing needs.
What are the main differences between Pocket Nc and traditional CNc machines?
Pocket Nc machines are compact, portable, and ofter simultaneous 5-axis machining capabiities, wheregs traditional cNc machines
may have fewer axes and are typically larger and stationary.
