Desktop Cnc Machine
Spindle: 24,000 rpm high speed
Precision transmission parts
Integrated housing
Servo Motor Speed: 12m/min
Operation: Quieter and faster
Performance: High responsiveness, precise positioning accuracy, and smooth operation without step losses
Description
Technical Parameters
Products Description
The Desktop cnc machine is a versatile and compact solution for high-precision machining, integrating five-axis functionality into a small, desktop-sized device. Ideal for prototyping and small-scale manufacturing, this machine can handle various materials like plastics, aluminum alloys, wood, copper, gold, silver, and wax. It delivers exceptional accuracy and efficiency, and its user-friendly tool bit system allows for easy and quick changes without the need for wrenches. Whether for industrial applications or educational purposes, this machine is designed to meet the demands of modern machining tasks.
High-precision five-axis synchronous machining capability: Provides the ability to control five axes simultaneously, achieving precision machining of complex shapes, especially suitable for the manufacturing of parts that require multi-angle machining.
Efficient servo motor drive system: Equipped with No. 57 high-performance servo motor, it ensures fast response, noiseless operation and high positioning accuracy, and supports machining speeds up to 12m/min.
Multi-material compatibility and flexibility: Able to process a variety of materials including aluminum alloy, copper, steel, stainless steel, plastic, wood, wax, etc., to adapt to different machining needs and expand the scope of application.
Intelligent CNC system and easy-to-operate interface: Adopting intelligent CNC system, supporting CAD/CAM software integration, users can intuitively set machining paths and parameters, simplifying programming and operation processes.
Test video
A five-axis CNC test project purchased by the MIT intelligent robot team.
(Several projects designed by the team, including MIT Mini Cheetah: https://www.youtube.com/watch?v=xNeZWP5Mx9shttps://www.youtube.com/watch?v=G6fMV1UPzkg and the fastest Rubik's Cube solution in the worldRobot question: https://www.youtube.com/watch?v=nt00QzKuNVY uses Pocket NC machines to manufacture parts for similar robot projects.)
Tech Specs
| Packing Size | W800xD600xH800mm | Packing weight | 100-120kg |
| Equipment size | W600xD400x H510mm | weight of equipment | Net weight of 45kg,with sheet metal of 75kg |
| Bed Dimension | φ100mm | Maximum payload of the work table |
5kg |
| XYZ effective travel | X160xY200xZ130mm | AC effective travel | A:-30-120°,C 360° |
| Three axis processing range | X160xY200xZ125mm | Five axisprocessing range | Cylinder:φ 150 H105mm,φ 100 H120mm,cube W125D 125 H110mm |
| Three-axis processing accuracy | Linear axis parallelism & vertical degree of 0.03mm, Travel range is 0.02mm |
Five axis processing accuracy | Linear axis parallelism &vertical degree of 0.05mm, Fve-axis spatial accuracy of<0.05mm |
| XYZ Ball wire rod | X&Z:1204C7,Y:1604 C7,up gradable C5 | AC axis |
1:80 20 Harmonic reducer return<1' |
| The XYZ linear guide rail | X&Z Hiwin MGN12 Y:Hiwin MGN15 | body frame | 6061T6 aviation aluminum+stressed component adjustment of 45 steel |
| Processing speed | 4000mm/min vary by material | ||
| principal axis | φ65mm 800W Water-cooled electric spindle at 24,000r /min |
protect | Organ is dust-proof +oil seal is waterproof and dustproof |
| Tool diameter& length | ER11.0-8mm,≤75mm | Part fixtures | Steel fixture with reserved hole position Can add er50 clip holder,63,80 card |
| work material | Metal:aluminum alloy.copper alloy,gold alloy,silveralloy.*steel,*titanium alloy | Non-metat plastic,wood,wax,jade,glass etc |
Shipping List
| Order Number | Type | Name | Explain | Quantity |
| 7 | Equipment | Main Engine | Naked machine does not contain sheet metal |
1 |
| 2 | Material Fixtures | Type A: self-centering platform pliers |
8-55mm square ping | 1 |
| 3 | Knife fixture | ERlI clamp cylinder | ER11-4&ER11-6 | 1 |
| 4 | Cutter | Sharp knife,vertical miling cutter,ball knife |
0.2mm sharp knife (for carving)10 2,4,6mm vertical milling cutter 2, R ball knife 2 |
18 |
| 5 | Electrical | power box | Motor control frequengy converter | 1 |
| 6 | power line | Total power supply for equipment | 1 | |
| 7 | USB data wire | Connect the computer to the host machine | 1 | |
| 8 | Electronichand wheel | Operation shaft movement | 1 | |
| 9 | Tool | 1 set of inner agon wrench | 1.5-109PCS | 1 |
| 10 | A set of spindle wrench | 14 &17mm open-wrench | 1 | |
| 1 | Material | Generation wood 4 pieces | Practice with | 1 |
Options and upgrades
| Order Number | Type | Name | Explain | Quantity |
| 1 | Transmission | Domestic grinding of C5 silk rod | 1204 &1604 | 3 |
| 2 | Prindpal axis | 40000r pm | Also power 800W 65mm diameter | 1 |
| 3 | Knife Fixture | Spindle ER11 clip cartridge | 2~8mm full set | 10 |
| 4 | Square Material fixture | A self-centering clamp reverse clamp | 50-75mm clamp range | 1 |
| 5 | B increase self-centering pliers | 0-100 mm clamp range | 1 | |
| 6 | Stick fixture | Hand tight 80 clamp (four paws) |
Occupying height 48mm travel,can hold the rod material &square material |
1 |
| 7 | Metalworking 80 chuck (three caws) |
The height of 66mm travel,the centricity is better than the four daws |
1 | |
| 8 | ER40 splint | High grip concentricity,used with ER40 | 1 | |
| (ER50,ER40 two optional one) | cartridge (Clamp-holding Φ 4to 30 mm) | |||
| 9 | One set of ER40 clips | 6.8.10.12.15.18.20.25.28.30mm Clamp cylinder (corresponding to same diameter) |
10 | |
| 10 | ER50 splint | Use with ER50 cartridge (damp Φ 4-36mm) | 1 | |
| 11 | ER50 cartridge optional model | Within 4-36 mm of optional size,70 yuan each | 1 |
Application of Pocket cNC
Prototyping and Development:
Rapidly and efficiently produce complex prototypes and parts to accelerate product development.
Custom Parts Production:
|Particularly suitable for industries that require small-volume customization and high-precision processing, such as medical device and aerospace parts manufacturing.
Education and Research:
Provides an advanced CNC technology learning platform suitable for teaching and research in colleges and vocational training institutions.
Jewelry and Art Production:
Capable of accurately processing materials such as precious metals and wax, it is suitable for the production of high-end custom jewelry and complex works of art.
Product Advantages
High-precision processing capability
Desktop CNC machine tools have excellent precision and micron-level processing, which are suitable for precision operations in multiple fields, reduce errors, and improve quality and efficiency.
Compact and portable design
Desktop-level size, small footprint, light weight and portability, flexible placement, breaking through site restrictions, and easy to use.
Multi-functional processing application
Integrated with multiple processes, tool change and parameter adjustment can process multiple materials, one-stop solution, reduce costs and reduce management.
Easy to learn and operate
Intuitive operating interface, intelligent system, easy for novices to use, graphical programming, tutorial support, shortening production cycle and improving efficiency.
No matter what you need, please feel free to contact us.
Contact Us : xslightings@xslightings.com
fAQ
1.How accurate is the Desktop 5 Axis Milling Machine?
The machine offers exceptional precision for intricate and complex part production, achieving high accuracy and detailed results due to its five-axis capability.
2.What materials can be processed using the Desktop 5 Axis Milling Machine?
The machine supports the processing of a variety of materials, including plastics, aluminum alloys, wood, copper, gold, silver and wax,
3.What are the advantages of five-axis machining?
Five-axis machining can process workpieces from multiple angles, providing excellent precision and efficient manufacturing capabilities for complex parts.
4.How to change the machine's tools?
The machine has an easy-to-use tool change system, users can quickly change tools without a wrench, easy to operate, and improve work efficiency.
5.Is this machine suitable for educational purposes?
Yes, the Desktop 5-Axis Milling Machine is very suitable for education and training, helping students and professionals learn advanced machining techniques and operating methods.
6.Can the Small 5 Axis CNC be used for prototyping?
Yes, it is ideal for prototyping, allowing engineers and designers to create precise models and test designs efficiently in a compact format.
